KD-CPL76P-RED
76mm Nylon Short Shackle Safety Padlock — CPL76P
Pricing is provided by quotation based on quantity, specification, and destination.
Product details
The PROLOCKEY 76mm Nylon Short Shackle Safety Padlock is model CPL76P. Use the specifications and product images below to confirm suitability for the intended lockout/tagout application.
Product features
- Key Retaining Feature: When the shackle is open, the key can’t be removed.
- Laser printing and logo engraving available if required.
- All different colors available.
- Reinforced nylon body, withstand temperature from -20°C to +120°C . The steel shackleis chrome plated; the non-conductive shackle is made from nylon, withstandtemperature from -20°C to +120°C, ensuring the strength and deformation fracture noteasily.
Specifications
| Model | CPL76P |
|---|---|
| Material | Nylon Body,Nylon Shackle |
| Body Width | 37mm |
| Body Height | 45mm |
| Shackle Length | 3in (76mm) |
| Shackle Width | 25/32in (20mm) |
| Shackle Diameter | 1/4in (6mm) |
Configuration guide
- Color: select from the available product options.
- KD: each lock uses its own different key.
- KA: locks in the same keyed-alike group use the same key.
- Keys supplied: choose one or two keys per lock where listed.
Selection guidance
Confirm the model, dimensions, application fit and lock-hole compatibility before ordering. Installation and energy-isolation procedures must follow the site's authorized lockout/tagout program.
